Swimming 03 Windmeter

Swimming 03 Windmesser - Tifgang

The Swema 03 anemometer has a built-in barometer that automatically compensates for air density. Meets the requirements of ISO 7726 and ISO 7730 for ergonomic measurements of the thermal environment.


Features and Benefits:

  • Omnidirectional air speed
  • Air temperature measurement from 10 to 40°C
  • Barometer for pressure measurements from 600 to 1200 hPa
  • Response time < 0.2 seconds
  • Sampling frequency: Max. 100 Hz
  • USB port for easy connection
Swema 03+ Windmesser - Tiefgang

SPECIFICATION Swema 03 Wind Gauge - Draft

Measuring range
Air speed 0.05- 3.00 m/s at 15...30°C
Temperature 10...40°C
Barometer 600... 1200 hPa
Measurement inaccuracy
at 20...25°C: ±0.03 m/s at 0.05...1.0 m/s
at 20...25°C: ±3 % measured value at 1.0...3.0 m/s
at 15…30°C: ±0.04 m/s at 0.05...1.00 m/s
at 15…30°C: ±4 % measured value at 1.00...3.00 m/s
Temperature ±0,1°C
Barometer ±3,5 hPa

Description

Omnidirectional anemometer for low air speeds with USB output.


Swema 03+ has a built-in barometer. The measured air speed is therefore automatically compensated with the actual air density.


Swema 03+ meets the requirements of ISO 7726 for use with ISO 7730 – Ergonomics of the thermal environment:


1: The air velocity sensor must be direction-independent and sensitive to low air velocities. In rooms, the direction changes and the speed is approximately 0.05...0.4 m/s.


2: The response time of the sensor must be as short as possible.
Air turbulence is an important component of air velocity in the draft formula. Room air velocity can change from 0.05 m/s to 0.4 m/s in a very short time. It is important that the sensor follows these changes. ISO 7726 states that the desirable response time of an air velocity sensor should be less than 0.2 seconds (90%). See technical data. Swema 03 achieves the desired values by using a fast microcontroller and a small sensor element. (Other larger sensors have a greater inertia and therefore a longer response time).


The result is a tension sensor with particularly good dynamic properties in turbulence.


Swema 03 can be set up with multiple probes using the PC program SwemaMultipoint or as a single probe connection using SwemaTerminal 3. The SwemaMultipoint software can read values from Swema 03 at recommended 10 Hz with a selectable time constant of 0.1 seconds.


Swema 03+ can also be used with other software connected to USB.
