SwemaFlow 126

SwemaFlow 126 Luftstromhaube

SwemaFlow 126 is ideal for testing, adjusting and balancing (TAB) of exhaust and supply air flows.

The proven Swema principle, a network of hot wires, provides accurate readings over the entire measuring range. The hot wires together with the counter pressure method and the larger hood make it suitable for supply air, including airflows from angled outlets.

The measured values can be saved and transferred to the PC.


Features and Benefits of the Gaussmeter 5270

  • Supply and exhaust air flow
  • 1.5...125 l/s, 3...263 cfm
  • High accuracy and stability
  • Pressure drop compensation
  • Memory
  • temperature
  • barometer
  • Density compensation
  • True or standard flow
  • 150 grams lighter
  • Larger hoods for supply air
  • EN 16211, EN 12599 compliant
SwemaFlow 126 ist ideal zum Testen, Einstellen und Abgleichen (TAB) von Abluft- und Zuluftströmen.

SPECIFICATION SWEMAFLOW 126

Measuring range
Airflow 1,5...125 l/s, 5,4...450 m³/h, 3,2...263 cfm
Temperature 0...50 °C, 32...122 °F
Barometer 600...1200 hPa, 18...35 inHg
Measurement inaccuracy
Airflow ±3.0 % measured value (at 20...25 °C)
min. ±0.5 l/s, ±1.8 m3/h, ±1 cfm (at 20–25 °C)
Temperature ±0,5 °C, ±1,0 °F
Barometer ±3.5 hPa, ±0.1 inHg
Uncertainty of the backpressure method ±10% reading, minimum 1 l/s, 2.1 cfm
