SwemaFlow 236

SwemaFlow 236 Luftstromhaube

SwemaFlow 236 measures the airflow at exhaust valves in HVAC systems.

The unique Swema principle, a network of hot wires, delivers accurate measurements across the entire measuring range.


Features and Benefits of the Gaussmeter 5270

  • Exhaust air flow
  • 1...65 l/s, 2...137 cfm
  • High accuracy and stability
  • temperature
  • barometer
  • Density compensation
  • True or standard flow
  • EN 16211, EN 12599 compliant
SwemaFlow 236 misst den Luftstrom an Auslassventilen in HVAC-Systemen.

SPECIFICATION SwemaMan 7

Measuring range
Airflow 1...65 l/s, 3,6...234 m³/h, 2,1...137 cfm
Temperature 0...50 °C, 32...122 °F
Barometer 600...1200 hPa, 18...35 inHg
Measurement inaccuracy
Airflow ±3.5 % measured value (at 20...25 °C)
min ±1 l/s, 3.6 m³/h, ±2.1 cfm (at 20...25 °C)
Temperature ±1 °C, ±2 °F
Barometer ±3.5 hPa, ±0.1 inHg
