GM8030 Gaussmeter-Teslameter

Gaussmeter 8030

Please enquire about delivery time, mostly available from warehouse in Darmstadt


The Gaussmeter 8030 is a high precision 3-axis Gaussmeter from the manufacturer FWBELL , 3-channel table device for the simultaneous connection of up to three 1-axis probes or one 3-axis probe.

Optionally, the device can be ordered with a calibration certificate


Functions of the Gaussmeter 8030
  • wide range of probes, 3-axis or transverse or axial
  • automatic zeroing
  • Min/Max/Peak
  • Car area
    •
  • Gaussmeter
    •
  • -Desktop device with integrated power supply
    •
  • Intuitive menu control of the
  • Gaussmeter
  • can be operated with temperature compensated probes
    •
GM8030 Gaussmeter-Teslameter

SPECIFICATION GAUSSMETER GM8030

PARAMETER VALUE
Basic DC accuracy ±0.05% of measured value and ±0.01% of measuring range
frequency DC - 25 kHz
Measuring range 1G to 30kG
resolution 1mG - 10G
Readings 4/sec screen, 100K/sec (analog)
Analog output and
operating temperatur
dimension 292 x 132 x 368 mm
Weight here. 5.3 kg
Interfaces
